KTD-S0001-C Page 17 Graphics Interface
JRexplus LX User's Guide
7.6 Extended VESA Modes
VESA Mode Type Pixels Colors
101h Graphic 640 x 480 256
103h Graphic 800 x 600 256
105h Graphic 1024 x 768 256
107h Graphic 1280 x 1024 256
110h Graphic 640 x 480 32k
111h Graphic 640 x 480 64k
112h Graphic 640 x 480 16M
113h Graphic 800 x 600 32k
114h Graphic 800 x 600 64k
115h Graphic 800 x 600 16M
116h Graphic 1024 x 768 32k
117h Graphic 1024 x 768 64k
118h Graphic 1024 x 768 16M
119h Graphic 1280 x 1024 32k
11Ah Graphic 1280 x 1024 64k
11Bh Graphic 1280 x 1024 16M
131h Graphic 1600 x 1200 256
133h Graphic 1600 x 1200 64k
134h Graphic 1600 x 1200 16M
7.7 Backlight Connector
Backlight is available through the X19 connector (7 pins). Backlight voltage and backlight on/off polarity
are controlled through the jumper JP1 and JP2
Header Pin Signal Name Function
1 N.C. Not connected
2 BKLTADJ Brightness control (0V - 5V)
3 GND Ground
4 VCC 1) Power +5V or +12V
5 VCC 1) Power +5V or +12V
6 GND Ground
1
7
7 BKLTON Backlight on/off
Note: 1) To protect the external power lines of peripheral devices make sure that
- the wires have the right diameter to withstand the maximum available current.
- to enclosure of the peripheral device fulfills the fire-protecting conditions of IEC/EN 60950.
