Internal Graphics Configuration:
BIOS SETUP UTILITY
Chipset
Internal Graphics Configuration
Disabled
UMA
<- Select Screen
|| Select Item
Enter Go to Sub Screen
F1 General Help
F10 Save and Exit
ESC Exit
Internal Graphics Mode [UMA]
UMA Frame Buffer Size [Auto]
Current UMA Size [128MB]
Primary Video Controller [PCIE/IGFX/PCI]
Video Display Devices [Auto]
TV Standard [NTSC]
Expansion Mode [Disabled]
Replace GFX subid [Enabled]
V02.59+ (C)Copyright 1985-2005, American Megatrends, Inc.
Feature
Options
Description
Internal Graphics Mode
Disabled
UMA
Disabled
UMA
UMA Frame Buffer Size
Auto
32MB
64MB
128MB
256MB
512MB
1024MB
auto
32MB
64MB
128MB
256MB
512MB
1024MB
Primary Video Controller
PCIE/IGFX/PCI
PCI/PCIE/IGFX
IGFX/PCIE/PCI
PCIE/IGFX/PCI
PCI/PCIE/IGFX
IGFX/PCIE/PCI
Video Display Devices
Auto
CRT
LVDS
DVI
EDFP
TV
CRT + LVDS
CRT + DVI
CRT + EDFP
DVI + LVDS
DVI + EDFP
LVDS + EDFP
TV + LVDS
TV + DVI
TV + EDFP
Auto
CRT: onboard analogue VGA output
LVDS: onboard LVDS output
DVI: onboard DVI output
EDFP: External Digital Flat Panel via PCIe card
TV: onboard TV output (if TV-out version of board)
TV Standard
NTSC
PAL
PAL-M
PAL-60
NTSC-JAP
PAL-CN
Pal-N
Scart_RGB
NTSC
PAL
PAL-M
PAL-60
NTSC-JAP
PAL-CN
Pal-N
Scart_RGB
Expansion Mode
Enabled
Disabled
Enabled/Disabled Expansion Mode
