KT690 Family
KTD-00738-J
Public User Manual
Date 2012-06-01
Page
2
Document revision history.
Revision
Date
By
Comment
J
Jun. 1
st
2012
MLA
EOL products indicated. (Improved description of supported TV-
out connector, even though EOL).
I
Aug. 29
th
2011
MLA
Removed BIOS option “Replace GFX subid”. Info
“HyperMemory” removed. Added passive cooler.
H
Mar. 23
rd
2011
MLA
Added info on System Overview. Added support of Windows 7.
G
Jan. 19
th
2011
MLA
New BIOS option “Replace GFX subid”. Added note on XP Video
Driver (OS setup). Added Power consumption for BGA versions.
F
Sep. 9
th
2010
MLA
Added KT690/mITX BGA. Minor corrections.
E
Apr. 22
nd
2010
MLA
Feature connector corrections and added note on pin 3 and 4.
Added “mounting the board to chassis”. Memory size has been
corrected. Added warning to Installation Guide (turn off PSU).
D
May. 14
th
2009
MLA
Correction to LAN connector pinning. Battery alternative added.
Added BIOS setting: Default init boot order. Correted Force Boot
Devices. Corrected Video Display Devices.
C
Sep. 16
th
2008
MLA
Added FDD cable info. Corrections to Floppy connector. CPU
List updated. Added Clock Distribution.
B
Aug. 11
th
2008
MLA
Battery lifetime info added. Minor corrections, additions and
layout improvements.
A
Jul. 23
rd
, 2008
PJA
Updated
0
Dec. 11
th
, 2007
PJA
First preliminary manual version.
