KT690 Family
KTD-00738-J Public User Manual Date 2012-06-01 Page 62
6. System Ressources
Memory map 6.1
Address range (hex) Size (bytes) Description
00000000 0009FFFF 655359 System board
000A0000 000BFFFF 131071 ATI Radeon X1200 Series
000A0000 000BFFFF 131071 PCI bus
000A0000 000BFFFF 131071 PCI standart PCI-to-PCI brigde
000C0000 000CFFFF 65535 System board
000D0000 000DFFFF 65535 PCI bus
000E0000 000FFFFF 131071 System board
00100000 37FFFFFF 938475519 System board
38000000 3FFFFFFF 134217727 Motherboard resources
38000000 DFFFFFFF 2818572287 PCI bus
E0000000 EFFFFFFF 268435455 Motherboard resources
F0000000 F7FFFFFF 134217727 ATI Radeon X1200 Series
F0000000 F7FFFFFF 134217727 PCI standart PCI-to-PCI brigde
F0000000 FED44FFF 248795135 PCI bus
FE7F4000 FE7F7FFF 16383 Microsoft UAA Bus Driver for High Definition Audio
FE7FA000 FE7FAFFF 4095 Standard OpenHCD USB Host Controller
FE7FB000 FE7FBFFF 4095 Standard OpenHCD USB Host Controller
FE7FC000 FE7FCFFF 4095 Standard OpenHCD USB Host Controller
FE7FD000 FE7FDFFF 4095 Standard OpenHCD USB Host Controller
FE7FE000 FE7FEFFF 4095 Standard OpenHCD USB Host Controller
FE7FF000 FE7FFFFF 4095 Standard Enchanced PCI to USB Host Controller
FE7FF800 FE7FFBFF 1023 Standart Dual Channel PCI IDE Controller
FE800000 FE8FFFFF 1048575 ATI Radeon X1200 Series
FE800000 FE9FFFFF 2097151 PCI standart PCI-to-PCI brigde
FE9F0000 FE9FFFFF 65535 ATI Radeon X1200 Series
FEA00000 FEAFFFFF 1048575 PCI standart PCI-to-PCI brigde
FEAFF000 FEAFFFFF 4095 Realtek RTL8168/8111 PCI-E Gigabit Ethernet NIC
FEB00000 FEBFFFFF 1048575 PCI standart PCI-to-PCI brigde
FEBFF000 FEBFFFFF 4095 Realtek RTL8168/8111 PCI-E Gigabit Ethernet NIC
FEC00000 FEC00FFF 4095 Motherboard resources
FED00000 FED003FF 1023 High precision event timer
FED45000 FFFFFFFF 19640319 System board
FEE00000 FEE00FFF 4095 Motherboard resources
FFB80000 FFBFFFFF 524287 Motherboard resources
