KT690 Family
KTD-00738-J Public User Manual Date 2012-06-01 Page 75
8.3.7 Advanced settings – Voltage Monitor
BIOS SETUP UTILITY
Advanced
Voltage Monitor Enable Hardware Health
Monitoring Device.
<- Select Screen
|| Select Item
+- change option
F1 General Help
F10 Save and Exit
ESC Exit
Requested Core :1.100 V
Vcore :1.088 V
AVCC :3.248 V
3VCC :3.248 V
+12Vin :12.029 V
-12Vin :Good
+5Vin :5.165 V
Core 1.8 V :1.792 V
Core 1.2 V :1.184 V
VSB :3.264 V
VBAT :3.200 V
V02.59+ (C)Copyright 1985-2005, American Megatrends, Inc.
8.3.8 Advanced settings – ACPI Configuration
BIOS SETUP UTILITY
Advanced
ACPI Settings General ACPI
Configuration settings
<- Select Screen
|| Select Item
+- change option
F1 General Help
F10 Save and Exit
ESC Exit
>Advanced ACPI Configuration
>Chipset ACPI Configuration
V02.59+ (C)Copyright 1985-2005, American Megatrends, Inc.
Advanced ACPI Configuration
Feature Options Description
ACPI Version Features ACPI v1.0
ACPI v2.0
ACPI v3.0 Enable RSDP pointers to 64-bit Fixed System
Description Tables. Di ACPI version has some.
ACPI APIC support Disbled
Enabled Include ACPI APIC table pointer to RSDT pointer list.
Suspend mode S1 (POS) *
S3 (STR)
Auto Select the ACPI state used for System Suspend
Repost Video on S3 Resume No
Yes Determines whether to invoke VGA BIOS post on
S3/STR resume
Chipset ACPI Configuration
Feature Options Description
HPET in SB Disabled
Enabled Enable/Disable
