System Memory
3.4
The motherboard provides two 200-pin DDR2 Small Outline Dual Inline Memory Module (SO-DIMM) sockets.
Each slot can be populated with up to 16 GB of unbuffered DDR2 SO-DIMM modules resulting in a
maximum of 32 GB system memory. (PT only up to 2x 4GB has been verified). Memory speeds up to DDR2-
667 (PC2-5300) are supported.
3.4.1 Memory Configuration
Dual Channel configuration (128 bit) is enabled by populating both memory channels (DDR2 SLOT 1 and
DDR2 SLOT 1). Populating only one memory slot results in 64-bit Single Channel mode.
Mode
DDR2 SLOT 1
DDR2 SLOT 2
Single Channel (64 bit)
Populated
-
-
Populated
Dual Channel (128 bit)
Populated
Populated
