KT690 Family
KTD-00738-J
Public User Manual
Date 2012-06-01
Page
36
4.4.4 TV-Out (Optional)
The KT690/mITX boards include TV-Out connector with support for Component, S-Video and Composite
Output interfaces and NTSC/ PAL output format.
The KT690 board includes Macrovision support.
IMPORTANT
: If the TV-Out option is available then you must make agreement with Macrovision
licence fee which depends on the application.
KT690/mITX TV-Out connector:
Note
Pull
U/D
Ioh/Iol
Type
Signal
PIN
Signal
Type
Ioh/Iol
Pull
U/D
Note
GND
TVDACC
4 7 3
TVDACB
GND
2 6 5
1
GND
GND
TVDACA
Signal
Description
TVDACA
TVDAC Channel A output supports:
Composite: CVBS signal
Component: Chrominance (Pb) analog signal
TVDACB
TVDAC Channel B output supports:
S-Video: Luminance analog signal
Component: Luminance (Y) analog signal
TVDACC
TVDAC Channel C output supports:
S-Video: Chrominance analog signal
Component: Chrominance (Pr) analog signal
KT690/mITX-FW TV-Out connector:
Note
Pull
U/D
Ioh/Iol
Type
Signal
PIN
Signal
Type
Ioh/Iol
Pull
U/D
Note
TVDACC
1
2
TVDACB
SMBC
3
4
TVDACA
SMBD
5
6
-12V
+5V
7
8
+12V
GND
9
10
GND
