8.3.6 Advanced settings – Hardware Health Configuration

BIOS SETUP UTILITY

Advanced

Hardware Health Configuration

Disable = Full Speed

Thermal: Does regulate
fan speed according to
specified temperature

Speed: Does regulate
according to specified
RPM






<- Select Screen
|| Select Item
+- change option
F1 General Help
F10 Save and Exit
ESC Exit

System Temperature :37ºC/98ºF
CPU Temperature :43ºC/109ºF
External Temperature Sensor :N/A

System Fan Speed :Fail
Fan Cruise Control [Disabled]
Fan Type [4 Wire]
CPUFan0 Speed :2537 RPM
Fan Cruise Control [Thermal]
Fan Setting [45°C/113°F]
Fan Type [4 Wire]
AUXFAN Speed :2164
Fan Cruise Control [Speed]
Fan Setting [2177 RPM]

Watchdog Function [Disabled]

V02.59+ (C)Copyright 1985-2005, American Megatrends, Inc.


Feature

Options

Description

Fan Cruise Control

Disabled
Thermal
Speed

Select how the Fan shall operate.

When set to Thermal, the Fan will start to run at the
CPU die temperature set below.

When set to Speed, the Fan will run at the Fixed
speed set below.

Fan Type

4 wire
3 wire

Select the electrical interface for the fan:

3 Wire = PWM output to fan power line. RPM reading
and speed regulation at lower speed might be poor.

4 Wire = 12VDC always PWM on control signal

Fan Settings

1406-5625 RPM
30°-75°C

The fan can operate in Thermal mode or in a fixed
fan speed mode

Watchdog

Disabled
15 seconds
30 seconds
1 minute
2 minutes
5 minutes
10 minutes

To be serviced via API.
