KT690 Family
KTD-00738-J Public User Manual Date 2012-06-01 Page 32
Display Connectors 4.4
The KT690 board provides:
1. Analog CRT interface (IO Bracket)
2. Digital DVI (DVI-D) (IO Bracket)
3. LVDS connector (internal connector)
4. TV-Out (IO Bracket) (“KT690/mITX w. TV-out” only)
5. TV-Out (Internal pin header) (“KT690/mITX-FW w. TV-out” only)
The KT690 board does not support ADD2 / SDVO cards on the PCI Express x16 connector.
The KT690 integrates the ATI Radeon™ X1250 Graphics Core with support for Dual Clone display and Dual
independent display.
The supported combinations are listed in the below matrix:
Primary Display
CRT DVI-D LVDS TV-Out
S
eco
n
d
a
ry
D
isp
lay
CRT Clone / Dual Clone / Dual Not supported
DVI-D Clone / Dual Clone / Dual Clone / Dual
LVDS Clone / Dual Clone / Dual Clone / Dual
TV-Out Not supported Clone / Dual Clone / Dual
