KT690 Family

KTD-00738-J

Public User Manual

Date 2012-06-01

Page

65

I/O Map

6.4

Address (hex)

Size

Description

0020

0021

2

Programmable interupt controller

0040

0043

4

System timer

0060

0060

1

Standard Keyboard

0061

0061

1

System speaker

0064

0064

1

Standard Keyboard

0070

0071

2

System CMOS/Real time clock

00F0

00FF

16

Numeric data processor

0170

0177

8

Secondary IDE Channel

01F0

01F7

8

Primary IDE Channel

0274

0277

4

ISAPNP Read Data Port

0279

0279

1

ISAPNP Read Data Port

02F8

02FF

8

Com2

0376

0376

1

Secondary IDE Channel

0378

037F

8

LPT1

03B0

03BB

12

PCI-to-PCI brigde

03C0

03DF

32

PCI-to-PCI brigde

03F6

03F6

1

Primary IDE Channel

0A79

0A79

1

ISAPNP Read Data Port

0B00

0B0F

16

ATI SMBus

7000

700F

16

Standart Dual Channel PCI IDE Controller

8000

8003

4

Standart Dual Channel PCI IDE Controller

9000

9007

8

Standart Dual Channel PCI IDE Controller

A000

A003

4

Standart Dual Channel PCI IDE Controller

B000

B007

8

Standart Dual Channel PCI IDE Controller

C000

CFFF

4096

PCI-to-PCI brigde

C000

C0FF

256

ATI Radeon X1200 Series

D000

DFFF

4096

PCI-to-PCI brigde

D800

D8FF

256

Realtek RTL8168/8111 PCI-E Gigabit Ethernet NIC

E000

EFFF

4096

PCI-to-PCI brigde

E800

E8FF

256

Realtek RTL8168/8111 PCI-E Gigabit Ethernet NIC 2

FF00

FF0F

16

Standart Dual Channel PCI IDE Controller


Notes: This is the IO map after a standard Windows XP SP2 installation

DMA Channel Usage

6.5

DMA Channel Number

Data Width

System Ressources

0

8 or 16 bits

Available

1

8 or 16 bits

Available

2

8 or 16 bits

Available

3

8 or 16 bits

Available

4

8 or 16 bits

DMA Controller

5

16 bits

Available

6

16 bits

Available

7

16 bits

Available
