KT690 Family
KTD-00738-J Public User Manual Date 2012-06-01 Page 69
8.3.2 Advanced settings – IDE Configuration
BIOS SETUP UTILITY
Advanced
IDE Configuration Options
Controls the 40Pin
PATA connector and
CF interface.
<- Select Screen
|| Select Item
+- change option
F1 General Help
F10 Save and Exit
ESC Exit
OnBoard PCI IDE Controller [Primary]
OnChip SATA Type [Enabled]
OnChip SATA Channel [Native IDE]
Primary IDE Master : [Hard Disk]
Secondary IDE Master : [Not Detected]
Third IDE Master : [Not Detected]
Third IDE Slave : [Not Detected]
Fourth IDE Master : [Not Detected]
Fourth IDE Slave : [Not Detected]
Hard Disk Write Protect [Disabled]
IDE Detect Time Out (Sec) [35]
ATA(PI) 80Pin Cable Detection [Host & Device]
V02.59+ (C)Copyright 1985-2005, American Megatrends, Inc.
Feature Options Description
OnBoard PCI IDE Controller Disable
Primary
Controls the 40Pin PATA connector and CF
interface.
Feature Options Description
OnChip SATA Channel Enabled
Disabled
Enabled/Disabled the SATA circuit
OnChip SATA Channel Native IDE
RAID
AHCI
Legacy IDE
Native IDE
RAID (Press to enter RAID BIOS menu)
AHCI
Legacy IDE
Feature Options Description
Hard Disk Write Protect Disabled
Enabled Disabled
Enhanced
IDE Detect Time Out (Sec) 0
5
10
15
20
25
30
35
Select the time out value for detecting ATA/ATAPI
device(s)
ATA(PI) 80Pin Cable
Detection Host & Device
Host
Device Select the mechanism for detecting 80Pin ATA(PI)
Cable
