KT690 Family
KTD-00738-J
Public User Manual
Date 2012-06-01
Page
11
3. System specification
Component main data
3.1
The table below summarises the features of the KT690/mITX, KT690/mITX-FW and KT690/mITX (BGA)
embedded motherboards.
Form factor
KT690/mITX, KT690/mITX-FW and KT690/mITX (BGA): mini ITX (170.18 x 170.18mm)
Processor
• Support for Mobile AMD Sempron™, AMD Turion™ 64 and AMD Turion™ 64 X2
Mobile Processors for S1 socket. (KT690/mITX and KT690/mITX-FW only).
o
35W maximum TDP
o
6.4GB/s HyperTransport™ link, 800 MHz, 16bit/16bit
o
Hypertransport™ 1.0 Tunnel (I/O Bus) speed of 800MHz
o
Internal L1 cache of 128KB (Single core CPUs) / 128KB x2 (Dual core CPUs)
o
Internal L2 cache of 128/256/512KB (Single core CPUs) / 512KB x2 (Dual
core CPUs)
o
Processor technology of 65nm / 90nm
• Support for AMD Sempron
TM
BGA Single Core 210U (KT690/mITX (BGA) only).
o
15W maximum TDP
o
Up to 6.4GB/s peak HyperTransport™ link, 800 MHz, 16bit/16bit
o
Internal L1 data cache 64KB + L1 instruktion cache 64KB
o
Internal L2 cache of 256KB
o
Processor technology of 65nm
• Support for AMD Athlon
TM
Neo X2 BGA Dual Core L325 KT690/mITX (BGA) only.
o
18W maximum TDP
o
Up to 6.4GB/s peak HyperTransport™ link, 800 MHz, 16bit/16bit
o
Internal L1 data cache 2x 64KB + L1 instruktion cache 2x 64KB
o
Internal L2 cache of 2x 512KB
o
Processor technology of 65nm
• DDR2 memory controller and bus interface
Memory
• Dual Channel DDR2 memory architecture
• 2 pcs DDR2 SODIMM 200pin DRAM sockets onboard.
• Support DDR 400/533/667MHz unbuffered memory (PC2-3200/PC2-4200/PC2-5300)
• Support system memory from 1x 256MB and up to 2 x16GB (PT only up to 2x4GB
has been verified).
• ECC not supported
Chipset
AMD Chipset consisting of:
• AMD M690T northbridge ( graphics tunnel)
• ATI SB600 southbridge (I/O hub)
Video
• Integrated ATI Radeon™ X1200 graphics core
o
CRT Out connector
o
DVI-D connector (Digital only)
o
Onboard LVDS connector
o
TV-Out connector (only configuration “KT690/mITX w TV out”)
o
TV-Out pin connector (only configuration “KT690/mITX-FW w TV-out”)
• Dual independent pipe support: Mirror and Dual Independent displays supported.
• Full DirectX® 9.0 support
• Maximum resolution of 2048x1536 @ 32bpp for a maximum pixel clock speed of
400MHz.
• LVDS interface supports dual channel, 24bit OpenLDI/ SPWG panels.
(continues)
