KT690 Family
KTD-00738-J Public User Manual Date 2012-06-01 Page 61
5. Onboard Connectors
Connector
Onboard Connectors Mating Connectors
Manufacturer Type no. Manufacturer Type no.
FAN_SYS, Molex 22-23-2031 AMP 1375820-3
FAN_CPU
KBDMSE Molex 22-23-2061 Molex 22-01-2065
CDROM Foxconn HF1104E Molex 50-57-9404
Molex 70543-0038
SATA0-3 Molex 67491-0020 Molex 67489-8005
Kontron KT 821035 (cable kit)
IEEE1394_0
IEEE1394_1
Foxconn HC11051-P9 Kontron KT 821040 (cable kit)
ATXPWR Foxconn HM2510E Molex 39-01-2205
COM1 + COM2 Foxconn HL20051 Molex 90635-1103
Kontron KT 821016 (cable kit)
Kontron KT 821017 (cable kit)
USB6
USB7
Foxconn HC11051-P9 Kontron KT 821401 (cable kit)
PRINTER Foxconn HL2213F Molex 90635-1263
Kontron KT 821031 (cable kit)
AUDIO_HEAD Molex 87831-2620 Molex 51110-2651
Kontron KT 821043 (cable kit)
FRONTPNL Foxconn HL20121 Molex 90635-1243
Kontron KT 821042 (cable kit)
FEATURE Molex 87831-3020 Molex 51110-3051
Kontron KT 821041 (cable kit)
LVDS Don Connex C44-40BSB1-G Don Connex A32-40-C-G-B-1
Kontron KT 821515 (cable kit)
Kontron KT 821155 (cable kit)
