DC Voltage Chart
Voltages are approximate and will vary up to +/- 10% due to normal component variation without
affecting the operation of the KRC2. Measurements were made under the following conditions:
KRC2 powered by K2, K2 powered by a 14.0 V (measured) power supply, K2 powered on, set to
14290.9 MHz. Switch to this band from another after powering on K2/KRC2 combination.
Nothing attached to the KRC2’s DC barrel jack or PC DB9 connectors. No wires attached to the
J4-J13 terminal connectors. Measurements taken with Metex ME-22 Digital Volt Meter.
Pin V Pin V Pin V Pin V Pin V
U1 P1 4.75 U1 P27 4.56 U2 P13 4.95 U5 P7 0.00 U6 P17 0.00
U1 P2 2.77 U1 P28 0.00 U2 P14 0.00 U5 P8 0.00 U6 P18 0.00
U1 P3 3.45 U1 P29 4.56 U2 P15 4.95 U5 P9 0.00 U6 P19 0.00
U1 P4 0.00 U1 P30 0.00 U2 P16 4.95 U5 P10 0.00 U6 P20 0.00
U1 P5 0.00 U1 P31 0.00 U4 P1 0.00 U5 P11 0.00 U7 P1 0.00
U1 P6 0.79 U1 P32 4.95 U4 P2 4.95 U5 P12 0.00 U7 P2 4.95
U1 P7 4.93 U1 P33 4.95 U4 P3 4.95 U5 P13 13.35 U7 P3 0.00
U1 P8 5.55 U1 P34 4.95 U4 P4 0.00 U5 P14 0.00 U7 P4 0.00
U1 P9 1.97 U1 P35 4.95 U4 P5 0.00 U5 P15 4.95 U7 P5 0.00
U1 P10 4.63 U1 P36 4.95 U4 P6 0.00 U5 P16 0.00 U7 P6 0.00
U1 P11 4.95 U1 P37 4.95 U4 P7 0.00 U6 P1 0.00 U7 P7 0.00
U1 P12 0.00 U1 P38 4.95 U4 P8 0.00 U6 P2 4.95 U7 P8 4.95
U1 P13 1.77 U1 P39 4.95 U4 P9 0.00 U6 P3 4.95 U7 P9 0.00
U1 P14 2.21 U1 P40 4.95 U4 P10 0.00 U6 P4 0.00 U7 P10 0.00
U1 P15 4.93 U2 P1 12.86 U4 P11 0.00 U6 P5 0.00 U7 P11 0.00
U1 P16 0.00 U2 P2 0.00 U4 P12 0.00 U6 P6 0.00 U7 P12 0.00
U1 P17 4.90 U2 P3 12.42 U4 P13 13.35 U6 P7 0.00 U7 P13 4.95
U1 P18 4.95 U2 P4 -2.52 U4 P14 0.00 U6 P8 4.95 U7 P14 0.00
U1 P19 4.93 U2 P5 -7.56 U4 P15 4.95 U6 P9 0.00 U7 P15 0.00
U1 P20 4.93 U2 P6 -6.80 U4 P16 0.00 U6 P10 0.00 U7 P16 0.00
U1 P21 4.93 U2 P7 12.42 U5 P1 0.00 U6 P11 0.00 U7 P17 0.00
U1 P22 4.93 U2 P8 -7.55 U5 P2 4.95 U6 P12 0.00 U7 P18 0.00
U1 P23 4.93 U2 P9 0.00 U5 P3 0.00 U6 P13 4.95 U7 P19 0.00
U1 P24 4.95 U2 P10 0.00 U5 P4 0.00 U6 P14 0.00 U7 P20 0.00
U1 P25 4.95 U2 P11 4.95 U5 P5 0.00 U6 P15 0.00
U1 P26 4.95 U2 P12 4.95 U5 P6 11.97 U6 P16 0.00
Note: U6 Pins 4, 5, 6, 7, 14, 15, 16, 17 and U7 Pins 4, 6, 7, 14, 15, 16, 17 are floating (not driven)
with no pullup. U6 pin 5 is driven to zero for 14 MHz as shown in the voltage chart.
