A5
KPA500 Misc. Bag. – E850452
ILLUSTRATION DESCRIPTION QTY.
ELECRAFT
PART NO.
Heat Spreader 1 E100386
Hex Nut, 4-40, Zinc 1 E700011
Hex Nut, 5/16” (7.9 mm), 18 tpi 1 E700230
Standoff, 4-40, 1/2” (13mm) 1 E700061
Screw, 4-40, 3/8" (9.5 mm) Flat Head,
Black
1 E700131
Screw, 2-56 1/2” (13mm) Flat Head,
Black
2 E700200
Nut, Nylock, 5/16” (7.9 mm) 1 E700221
Bolt, Fully Threaded 5/16” (7.9 mm) x
3.5”L (8.9 cm), 18 tpi
1 E700222
Washer, Belleville, 0.38” (9.7mm) Inside
Diameter.
1 E700225
Washer, Fender, 5/16” (7.9mm), Zinc 2 E700231
Front Feet with Stand
Rear Feet
Tilt Stand with Rear Feet 1 E980098
Screw, 4-40, 3/8” (9.5mm), Zinc, Pan
Head
2 E700036
Screw, 4-40, 7/16” (11mm) Zinc, Pan
Head
4 E700032
Screw, 4-40, 1/4” (6.4 mm), Zinc, Pan
Head
11 E700005
Lock Washer, #2, Split Ring 2 E700123
Lock Washer, #4, Split Ring 3 E700004
Lock Washer, 5/16” (7.9mm) Split Ring 1 E700232
