EFCO 8800 Series Assembly Instructions Vol.5 User Manual
Page 89

EFCO 2009
Page 89
Series 8700 / 8800 Unitized Curtain Wall Assembly Instructions - Volume 5
Section 32 - Mounting Vent Assembly Into Unit Frame
Allen Keyed Release Limit Arm
Limit Arm Track
Mounting Bracket
Security Screw
Arm
Guide Shoe With
Friction Pad
Secure Position
Top Plate
Figure 230
Security Screw
Loosen security
screw.
Slide assembly
upward.
Disengage assembly from
mounting bracket.
Releasable Arm Procedure
1
2
3
4
