Detex DTX-2300 - Manual (Page 3)

Prox.pad Installer Guide
Document # 6-055678 X2 Page 3 of 32
prox.pad Pin Connector Table
Pin Connector (on main circuit board) Description/Use
P1 (5-pin connector, top left-most location)
Pin
1
2
3
4
5
Wire Color
Gray
Green
Blue
Black
Red
Use
Main Relay Normally Open
Main Relay Normally Closed
Main Relay Common
Ground (Power Supply)
+12V Input (Power Supply)
P3 (4-pin connector, top middle location)
Pin
1
2
3
4
Wire Color
Blue
Brown
White
Green
Use
Not Used
Wiegand LED Control
Wiegand Data 1
Wiegand Data 0
P2 (6-pin connector, top right most location)
Pin
1
2
3
4
5
6
Wire Color
Green
Gray
Blue
Brown
Orange
White
Use
Aux Relay Normally Open
Aux Relay Normally Closed
Aux Relay Common
REX Loop
Door Contact Loop
Loop Common
NOTE: Pins 1, 2, 3 can be wired at the installer’s option for one of the
following alarm outputs, Alarm Shunt, Forced Door, or Propped Door,
Mandatory: If you are not installing door contacts per Figure 11, twist the
white and orange wires together. If not done, the REX input won’t work
P4 (4-pin connector, bottom location)
Pin
1
2
3
4
Wire Color
Red
Black
White
White
Use
Bi-Color LED (Red +)
Bi-Color LED (Green +)l
Antenna (no polarity)
Antenna (no polarity
