Prox.pad Installer Guide
Document # 6-055678 X2 Page 26 of 32
Wiegand Programming Commands
If you need to change any of the program default values or wish to add functions, fi rst enter program mode and then enter
the desired program command. Defaults are in bold.
Note: The master code must be changed prior to performing any programming on the prox.pad unit.
Action Desired Press Details
Enter Program Mode 99 # (Master Code) ✱ Yellow LED blinks slowly
Change master code
1 # (new code) ✱ (repeat code) ✱
Ex: 1 # 4321
✱ 4321 ✱
Enter new code
Set/clear standard option 30 # option # s/c #
✱ ✱ See Chart Below
Option Set Clear
0 — Audio Keypress Feedback 1 = Enabled 0 = Disabled
1 — Visual Keypress Feedback 1 = Enabled 0 = Disabled
2 — Auto Entry 0 = Disabled 1 = Enabled
3 — Operating Mode 0 = Standalone 1 = Front End
9 — Wiegand Red LED Enable 0 = Disabled 1 = Enabled
10 — Wiegand Red LED Active State 0 = Low 1 = High
11 — Wiegand Green LED Enable 0 = Disabled 1 = Enabled
12 — Wiegand Green LED Active State 0 = Low 1 = High
15 — Front End Mode Select 0 = Wiegand Front End 1 = Secured Series Front End
Change Platform Parameters 32 # parameter # value #
✱ ✱
See Chart Below
Parameter Value
0 — Wiegand Pulse Width 1 — 255; 20µS increments;
(Defaults to 8 = 160µS)
1 — Wiegand Interpulse Spacing 1 — 255; 20µS increments;
(Defaults to 32 = 640µS)
Delete Entire Memory and Reset
System Defaults
46 # 00000 # 00000 #
✱ ✱
To exit Program mode Press ✱ Yellow stops fl ashing
