Detex DTX-2300 - Manual (Page 25)

Prox.pad Installer Guide
Document # 6-055678 X2 Page 25 of 32
Wiegand Mode LED/Sounder States
The table below describes the various LED and Sounder indications used in the prox.pad while in Wiegand Front End Mode.
LED/Sounder Visual/Audible Condition Description
Yellow LED
Slow blink Unit is in program mode
Rapid blink
Verify mode is active (checking that the last two values in
sequence match)
Steady Program error; entry error lockout (no keypress feedback)
Very rapid blink Memory (eeprom) erase is in progress (command 46)
Bi-Color LED
Steady red Lock is locked
Steady green Lock is energized (timed or latched)
Quick double red/green fl ash Prox card read correctly
All LED's
Rapid red/yellow, green
sequencing
Power on/reset
Sounder
(system)
Very quick beep (10 ms) with
yellow LED blink every second EEPROM read error during get system parameters; can be turned
off by running self-test
3 slow beeps (250 ms) Indicates self-test
Sounder (after
PIN)
Single long beep
Value entered too big, cannot be represented in 16 bits (Wiegand
mode)
Sounder (after
card
1 short beep Valid card access
Wiegand Front End Mode Default Settings
Option Default Setting Option Default Setting
Master Code 1234 Audio Keypress Feedback Enabled
Visual Keypress Feedback Enabled Auto-Entry Disabled
Wiegand Red LED Enabled Red LED Active State Low
Wiegand Green LED Enabled Green LED Active State High
Pulse Width 8 = 160µS Inter-pulse Spacing 32 = 640µS
