104832 Page 23
Catalog No: SN2 Stainless Steel BHMA 630 Finish
Catalog No: SN2 Brushed Brass BHMA 606 Finish
Catalog No: SN2 Brushed Chrome BHMA 626 Finish
Catalog No: SN2 Oil Rubbed Bronze BHMA 613 Finish
Dogging Lever Assembly
(shown for reference ONLY)
Security Screws
Key Stop Screw
(Momentary Shunt)
Key Stop Kit
Catalog No: KS
(Security Kit)
Catalog No: SSK3
Tamper Kit
R
Catalog No: SN1 Stainless Steel BHMA 630 Finish
Catalog No: SN1 Oil Rubbed Bronze BHMA 613 Finish
Catalog No: SN1 Brushed Brass BHMA 606 Finish
Catalog No: SN1 Brushed Chrome BHMA 626 Finish
The #10-32 kit is available in (4) finishes:
Flex Conduit Kit
Sex Nut
FCV-10
Catalog No: FCV-3
Catalog No: GB17 through GB21
#1/4-20 X 1-1/2" Self Drilling
screws Included
Glass Bead Kit
The #1/4-20 kit is available in (4) finishes:
Optional Accessories
Rod Cover/Bottom Bolt Guard Kit
P/N: 103562
Bottom Bolt Guard Kit
Wood Door Screw Kit
Part No: 103991
Security Pin TORX
Bits provided
FCV-W-10
Weatherized FCV-W-3
Dustproof Strike Kit
Part No: 101562-X
P/N:
103558-1 V50x84xRCxBG
103558-2 V50x96xRCxBG
103558-3 V50x120xRCxBG
103558-4 V51x84xRC
103558-5 V51x96xRC
103558-6 V51x120xRC
103558-7 V50x84xRC
103558-8 V50x96xRC
103558-9 V50x120xRC
