27 Pro 2 Operation Manual Filter Envelopes 1 & 2
Filter Envelopes 1 & 2
Each of the Pro 2’s two filters has its own dedicated, five-stage envelope
generator. A filter envelope is used to shape how a sound’s timbre or
harmonic content changes over time during its attack, decay, sustain, and
release stages. The Pro 2’s filter envelopes provide additional controls
for looping the envelope and for modulating the envelope amount using
keyboard velocity.
Sustain Release Attack Envelope
Amount
Decay
Sustain Release Attack Envelope
Amount
Decay
FILTER 1: ENVELOPE
FILTER 2: ENVELOPE
In addition to the front panel controls for each filter, there are also several
parameters accessible through the OLED display.
A:25
Attack Sustain Decay Release
D:36 R:44 S:52
F2 ADSR F2 Env Amt F1Env Amt F1 ADSR
0
DELAY
Delay Amount Env Repeat Vel Amt
ENV REPEAT
25
AMOUNT
6
VEL AMT
F1 Env Amt F2 ADSR F2 Env Amt F1 ADSR
