28 Filter Envelopes 1 & 2 Dave Smith Instruments
Delay: 0...127 — (In the F1
amt
and F2
amt
tabs of the display) Sets
a delay between the time the envelope is gated on and when the Attack
segment actually begins.
Attack: 0...127 —Sets the attack time of the envelope.
Decay: 0...127 —Sets the decay time of the envelope.
Sustain: 0...127 —Sets the sustain level of the envelope.
Release: 0...127 —Sets the release time of the envelope.
Attack Decay Sustain Release Delay
DADSR Envelope
Amplitude
Time
Env Repeat: Off, On —When on, the Delay, Attack, and Decay segments
of the envelope repeat. Sustain still affects the level at which the Decay
segment ends, but instead of sustaining at a fixed level while a note is
gated on, Delay, Attack, and Decay loop until the note is turned off. The
Release segment begins when the note is gated off, just as it does when
Repeat is off. See the illustration below.
On
A
B
C
Off
