Appendix i login to web-based interface manually – Compex Technologies WP11A+ User Manual

Page 90

Appendix I

In Netscape Communicator

1. Select

the

File menu, and then click on the Open Page.

2. In

the

Open Page dialog box, key in the IP address of the Compex WP11A+. This

address is set at the factory to: http://192.168.168.1.

3. Make sure the Navigator radio button is selected. Then click the “Open” button.

In Internet Explorer

1. Select

the

File menu, then select Open.

2. In

the

Open Page dialog box, key in the IP address of the Compex WP11A+. This

address is set at the factory to: http://192.168.168.1.

3. Click on the “OK” button.

The following screen is displayed next in the Web browser program (Figure A1-1):

4. Type in the password and click on the “Log On!”. The default password is

“password”.

A1-1

Now you can start configuring Compex WP11A+.
