1.5 Panel Description
Indicator Description
1 Power LED Steady Green Light
Power is supplied to Compex WP11A+.
2 WLAN LED Steady Green Light
A link is connected.
Flashing Green Light
An activity is going on.
3 10M LED Steady Green Light
LAN connecting at 10Mbps.
4 100M LED Steady Green Light
LAN connecting at 100Mbps.
5 COL LED Steady Green Light
Collision occurs at the network segment.
6 FDX LED Steady Green Light
Network is in Full Duplex Mode.
No Light
Network is in Half Duplex Mode.
7 WLAN Speed LED
Total 5 LEDs Steady Green Light
More LEDs lighting up indicate a higher speed of
data transmission.
8 DIAG LED Steady Green Light
Compex WP11A+ is booting and loading firmware.
Flashing Green Light
Firmware is corrupted.
No Light
Firmware has been completely downloaded onto the
Compex WP11A+. The device is connected to the
network.
