Chapter 5 Configure Compex WP11A Using Web Interface
30
Figure 5.4c Access Point Client Setup
7. Next, you have the option to choose either 64-bit or 128-bit for WEP Encryption
from the WEP Setup as shown below. Select your option and click on the “Apply”
button.
Figure 5.4d Selecting WEP encryption method
Channel
The Direct Spread Sequence Spectrum (DSSS)
technology divides the 2.4GHz band into 14
frequency channels, where the number of freely-
se channels is subjected to the local regulations
of individual country/region, namely 14 channels
for Japan; 13 channels for European, except
France (ETSI); 11 channels for United States &
Canada (FCC) and 4 channels for France.
State
3 kinds of status: Associated: BSS
Mac Address, Authentication or
Association failed and Not connected.
Tx Rate
There are 4 types of transmission
rate, namely, 1Mbps; 2Mbps;
5.5Mbps and 11Mbps.
