Chapter 1 Product Overview
6
Indicator Description
9 AP Mode LED Steady Green Light
The device is in AP Bridge Mode or AP Client Mode.
No Light
The device is in Gateway mode.
10 Wireless Interface Built-in 11Mbps Wireless LAN PCMCIA Card to
support wireless client.
11 5V DC/2.1A Accepts 5V DC/2.1A input.
12 RJ45 Ethernet Port 10Base-T or 100-Base-TX Port connects to cable
modem or xDSL modem.
13 Reset Button Compex WP11A+ will reboot the device, set to
default setting or switch between the selections of
work mode.
For more details please refer to “Hardware Reset of
Compex WP11A+” on Page 78.
CAUTION
Do not remove the wireless Interface Card from Compex WP11A+.
