Chapter 9 Configuring Network Address Translation
59
2. Click on the “Port Forwarding” button to display the NAT Static Port Based
Entries GUI.
Figure 9.3b NAT Static Port Based Entries
3. Click on the “Add” button.
Figure 9.3c Add in new Port Based Entry
4. Enter the information, for example:
Private IP Address:192.168.168.14
Server Type: HTTP
5. Click on the “Add” button to add the address into the Port-based mapping table.
Known Server
It supports a pre-defined list of
common Internet applications. You
do not have to know which
TCP/UDP port a specific Internet
application is assigned to the virtual
server.
Custom Server
It enables the user to define the
TCP/UDP port number for the
Virtual Server (of which is not
supported by the Known Server)
