Chapter 6 Setting up Wide Area Network using Gateway Mode
35
6.3 Configure Compex WP11A+ using Web Interface
Figure 6.3a Physical layout for Wireless Broadband Internet Gateway
Assuming that Compex WP11A+ is in the default setting.
1. Activate the uConfig program, click on the “OpenWeb” button.
2. Go to the CONFIGURATION menu and click on Mode Selection. Select
Gateway mode and click on the “Apply” button. Next, click on the “Yes” button to
reboot the device.
WP11A
Cable/ADSL
Modem
Internet Workstation 1
Notebook
Workstation 2
