I English
Specifications
Video camera
recorder
System
Video recording system
Two rotar\' heads. Helical scanning
svstem
Audio recording system
Rotary heads, RCM system
Quantization: I2bits (Fs 32kHz,
stereo I, stereo 2), 16bits (Fs 48kHz,
stereo)
Video signal
NTSC color, FIA standards
Usable cassette
Mini DV cassette with logo printed
Tape speed
SP: Approx. 18.83 mm/s
LP: Approx. 12.57 mm/s
Recording/playback time
SP mode: 1 hour {DVM60)
LP mode: 1.5 hours (DVM60)
Fastforward/rewind time
Approx. 2 min. 30 s (DVM60) (using
with battery pack)
Approx. 1 min. 45 s (DVM60) (using
with AC power adaptor)
Image device
CCD (Charge Coupled Device 1 / 3")
Viewfinder
Electric viewfinder (color)
Lens
Combined power zoom lens, 120x
(Digital), lOx (Optical)
Focal distance
f = to 1 ^/ain. (4.0 to 40 mm)
(1 */2 to 15 in. (38 to 380 mm) when
converted into a 35 mm still
camera)
F 1.8-2.6
TTL autofocus system inner focus
wide macro system
Color temperature
Auto
Minimum illumination
3 lux at F 1.8
Illumination range
3 to 100,000 lux
Recommended illumination
More than 100 lux
LCD screen'
4 inches measured diagonally
3 Vr to 2 ^/s in. (80.7
X 58.9 mm)
On-screen display
I’N hCD/TFT active matrix method
Total dot number
112,086 (479 X 234)
input and output
connectors
S video output
4-pin mini DIN
Luminance signal: 1 Vp-p, 75 ohms,
unbalanced, sync negative
Chrominance signal: 0.286 Vp-p,
75 ohms, unbalanced
Audio/Video output
Special minijack, 1 Vp-p, 75 ohms,
unbalanced, svnc negative
327 mV, (at output impedance
more than 47 kilohms)
Output impedance with less than
2.2 kilohms/Stereo minijack (o 3.5
mm)
D'V input/output
4-pin special connector
Headphones jack
Stereo mini jack (o 3.5 mm)
MIC input
Stereo minijack (o 3.5mm);0.388mV,
DC2.5V
Input impedance 6.8 kilohms
CLANG jack
Stereo miniminijack
(0 2.5 mm)
Speaker
Dynamic-speaker
LASER LINK
Video/audio
IR space transmisssion system
according to EIAJ (Electric
Industries Association of Japan)
standards
Audio carrier wave'
Lch : 4.3MHz
Rch : 4.8MHz
Generäl
Power requirements
7.2 V (battery insertion input)
Average power consumption
4.4 W during camera recording
using viewfinder
5.8 W during camera recording
using LCD screen
Operating temperature
32"F tol04°F (OX to 40X)
Storage temperature
-4°F to 140°F (-20X to 60X)
Dimensions
Approx. 3 ^/s
X 4 ^/8 X 7 V 4 in. (w/
h/d) (96 X 109 X 183mm)
Mass
Approx.1 \b 13 oz (840g) excluding
(ho batlorv pack and tho cassette
Approx. 2 lb 1 oz (960g) including
tile batter\’ pack NP-F530, lithium
battery and cassette DVM60
Approx. 2 lb 6 oz (l .lkg) including
the battery pack NP-F730, lithium
battery and cassette DVM60
Approx. 2 lb 10 oz (1.2kg) including
the battery pack NP-F930, lithium
battery and cassette DVM60
Microphone
Electret condenser microphone.
Stereo type
Supplied accessories
See page 6.
AC power adaptor
Power requirements
H0to240V AC, 50/60 Hz
Power consumption
25 W
Output voltage
DC OUT: 8.4 V, 1.8 A
in operating
mode
Battery charge terminal; 8.4 V, 1.4 A
in charge mode
Application
Sony battery pack NP-F530, NP-
F730, NP-F930 lithium ion type
Operating temperature
32°F to 104°F (OX to 40X)
Storage temperature
-4X to 140X (-20X to 60X)
Dimensions (Approx.)
2 V 4 x l 3 / 4 x 4 V 4 i n . (w/h/d)(57
X 44 X 107 mm)
Mass (Approx.)
7 oz (190 g)
Design and specifications are
subject to change without notice.
>
CL
Q.
O
3
•o
n
3
107
