Loading Print Media

Proper print media loading helps prevent jams and ensures trouble-free printing.

Before loading print media, identify the recommended print side of the print media. This information is usually on the

print media package.

Loading Print Media in Standard and Optional Trays

NOTE:

To avoid paper jams, do not remove trays while a job prints.

All trays are loaded the same way.

1. Pull the tray out of the printer until it stops. Hold the tray with both hands, lift the front slightly, and remove it

from the printer.

2. Slide the width guides to the edge of the tray. The width guides should be fully extended.

NOTE:

For A4 paper, push the lever to the A4 position.

For 8.5"(Letter) paper, push the lever to the 8.5"(Letter) position.
