Dell 5100cn Color Laser Printer - Manual (Page 237)

Enter server-printer-name? : ps
server-printer-name is 'ps' (y/n)[y] : y
NOTICE: Type ps when the printer is a network connection printer.
9. Type the printer name to be registered with the system.
Enter printer-name? [dell5100cn] : dell5100cn
Printer-name is 'dell5100cn' (y/n)[y] : y
10. Specify the directory to install the utility. To install into /usr/local/dellbin5100cn, press the key. To
change the directory, specify one.
Enter Binary directory name? [/usr/local/dellbin5100cn] :
11. If this utility has been installed earlier, the user will be prompted whether to overwrite the earlier version.
directory is '/usr/local/dellbin5100cn' (y/n)[n] : y
12. If the server input at step 5 the printer connected by the network, type . If the server and the printer are
connected locally, type .
'dell5100cn'is network printer?:(y/n)[y] : y
13. When the other filters have been registered in your workstation, the following message appears. Type .
Do you want remove 'XXXXXX' filter and re-install (y/n) [y]
The software installation is complete.
NOTICE: When the printing settings are modified or changed by the Administration Tool (admintool) after the
installation, printing may not work.
Operation on HP-UX
Installation Procedure
NOTE: The host name of the output printer which you want to specify in step 6 must be pre-registered with a sam
command.
1. Insert the Drivers and Utilities CD into the CD-ROM drive of the local workstation.
2. Log on as a root account and extract the installation script from the Drivers and Utilities CD.
NOTICE: If you have no root privilege, contact your system administrator.
# mount -F cdfs -o cdcase /dev/dsk/c1t2d0 /cdrom
# cd /tmp
# cp /cdrom/unixfilt/hpux/uxfilter.tar /tmp
# tar xvf UXFILTER.tar
NOTE: /dev/ds/clt2d0 is an example. Specify the CD-ROM device file for all workstations.
3. Type ./install.sh and run the installer.
# ./install.sh
4. Select the printer model to install.
