Dell 5100cn Color Laser Printer - Manual (Page 62)

hook as shown in the graphic, and lightly pull the power cable. Then, plug the other end of the cable into the
grounded outlet.
15. Turn on the printer.
NOTE: The printer will automatically detect the attached tray(s) but will not detect the paper type.
16. Print a Printer Settings page to verify the optional 500-sheet tray module or 1000-sheet tray module is installed
correctly.
a. Press Menu.
b. Press until Configure appears, and then press or .
c. Press until Reports appears, and then press or .
d. Printer Settings is displayed. Press .
The Printer Settings page is printed.
e. Verify that 500 Sheet Tray Module and 1000 Sheet Tray Module are listed in the printer settings under
Printer Options.
If the tray modules are not listed, turn off the printer, unplug the power cable, and reinstall the optional 500-
sheet tray module and 1000-sheet tray module.
17. After loading paper in the optional tray, specify the paper type from the printer operator panel.
a. Press until the paper type for the installed tray appears, and then press .
18. If you installed the optional 500-sheet tray module and 1000-sheet tray module after installing the printer driver,
update your driver by following the instructions for each operating system. If the printer is on a network, update
the driver for each client.
When Using PCL Driver
Windows XP/Server 2003
1. Click Start ® Printers and Faxes.
2. Right-click this printer icon and select Properties.
3. Click the Options tab, and then select Get Information from Printer.
