40. Click the Paper Tab.
41. Change Paper Size to Legal.
42. Change the Paper source settings BOTH to "DEFAULT TRAY AS PER PRINTER".
43. Click OK.
44. Type in some gibberish in the body of the document and click Print!
Setup printing Envelope from Multipurpose Feeder
1. On the printer operator panel press MENU.
2. Press to get to Tray Settings.
3. Press to select Tray Settings.
4. Press to get to Paper Size. (ONLY ON 3x00cn)
5. Press to select Paper Size. (ONLY ON 3x00cn)
6. Press to get to MPF. (ONLY ON 3x00cn)
7. Press to select MPF. (ONLY ON 3x00cn)
8. Using and , select the appropriate paper size (Envelope). (ONLY ON 3x00cn)
9. Press the middle button, SELECT, once Envelope is displayed on the lower line, this puts a * by it. (ONLY ON
3x00cn)
10. Now we have the MPF Size set to Envelope. (ONLY ON 3x00cn)
11. Now press MENU to get back to Tray Settings/Paper Size.
12. Press to get to Paper Type.
13. Press to select Paper Type.
14. Press to get to MPF.
15. Press to select MPF.
16. Using and , select the appropriate paper type (Plain 1).
17. Press SELECT, once Plain 1 is displayed on the lower line.
18. Now we have the MPF Type set to Plain 1.
19. Now press MENU to get back to Ready to Print
20. Now insert the Envelope-sized stack of paper into the MPF.
21. On the screen MPF/Envelope will appear. (ONLY ON 3x00cn)
22. Press SELECT to confirm this. (ONLY ON 3x00cn)
23. Now on the screen MPF/Plain 1 will appear.
24. Press SELECT to confirm this.
25. We now have all the hardware settings on the printer correct
Now, all software settings screen shots are from WORD, this was done in Word. However if in any application, you go File
® Print and then click the Properties button, you will get this same driver properties window.
