Troubleshooting Your System
49
Bezel
The front bezel has status and attention indicators. You must remove the bezel to open the system.
Removing the Bezel
CAUTION:
Many repairs may only be done by a certified service technician. You should only perform
troubleshooting and simple repairs as authorized in your product documentation, or as directed by the
online or telephone service and support team. Damage due to servicing that is not authorized by Dell is
not covered by your warranty. Read and follow the safety instructions that came with the product.
1 Using the system key, unlock the front bezel. See Figure 5-2.
Figure 5-2. Removing the Bezel
2 Slide the latch down and pull the right edge of the bezel away from the front panel. See
Figure 5-2.
3 Pivot the bezel outward until it is at a right angle to the front panel.
4 Remove the bezel from the slots on the front panel.
keylock
latch
bezel
