140
Jumpers, Switches, and Connectors
www
.dell.com | support.dell.com
System Board Jumpers
Figure A-2 shows the location of the configuration jumpers on the system board. Table A-1 lists the
jumpers settings.
Figure A-2. System Board Jumpers
Table A-1. System Board Jumper Settings
Jumper Setting Description
J55 pins 1 and 2 (default) The password feature is enabled.
The password feature is disabled.
J55 pins 3 and 4 (default) The configuration settings in NVRAM are retained at system
boot.
The configuration settings in NVRAM are cleared at next
system boot.
jumpered unjumpered
