e.
f.
Click the Add button to display Wireless network properties. g.
Under the Association tab, enter the following information and click OK. h.
Network name (SSID): dell_device
Network Authentication: Open
Data encryption: Disabled
Ad hoc network: checked
Click the Move up button to move the newly added SSID to the top of the list. i.
Click OK to close the Property dialog box. j.
NOTE: When your operating system is earlier than Windows 2000, create settings according to
the manual of the wireless setting tool provided by your wireless device manufacturer.
For Windows Vista:
Open Control Panel. a.
Select Network and Internet. b.
Select Network and Sharing Center. c.
Select Connect to a network. d.
Select dell_device from the network items listed in Connect to a network. e.
Select Connect Anyway in the warning dialog box indicating you are entering an unsecured
area. f.
Click Close in the dialog box after confirming the connection is a success. g.
Check the IP address on your computer. 2.
e.g.: 1.2.3.4
Set the IP address on the printer. 3.
e.g.: 1.2.3.5
Open Dell Printer Configuration Web Tool using WEB browser. 4.
e.g.: http://1.2.3.5
Change the wireless setting of the printer on Dell Printer Configuration Web Tool. 5.
6.
7.
