Adding a listed card – Dell OptiPlex E1 User Manual
Page 34
Table 3-1. ICU Keys
Key(s)
Action
Displays the menu containing the underlined letter x and performs the operation indicated by the menu item
containing the underlined letter y. For example, to save a file (that is, to display the File menu and select the
Save menu option), press .
Moves from one control button or list to another.
Up- and
down-arrow
keys
Moves up and down through items in a list.
Highlights an item in a list.
Selects the highlighted button or item in a list.
Adding a Listed Card
NOTE:
If you want to add a configuration file that you received on diskette with a new expansion card, you must copy
the configuration file to the \db subdirectory on the backup copy of the ICU diskette. You should then reboot your
system and perform the following procedure to add the expansion card.
To add a listed card with the ICU, follow these steps:
1. Start the ICU as described in "
" found earlier in this chapter.
2. From the ICU window, click Add or select Add Card from the Configure menu.
3. Click the name of the category of card that you want to add. If you clicked Add in step 2, click OK.
A dialog box like the one in Figure 3-2 appears, listing the names of all available cards of that type.
Figure 3-2. Add Network Card Dialog Box
4. Select the name of the card you want to add.
If the card is not listed, see the next section, "
."
5. If you want the ICU to select the resources for the card, click OK. Otherwise, skip to step 6.
