ITC AVOXimeter 1000E Operator’s Manual
63
Replacing the Battery
Materials Needed : 1. # 0 Phillips screwdriver
2. Diagonal cutting pliers
3. Replacement battery with cable (E4-BATP)
4. Securing cording (packaged with replacement battery)
1. Steps 1 through 11 of the Cleaning the Optical Detector procedure on page
59 Must be performed before moving to step 2 of “Replacing the Battery”,
below.
Note: The battery is housed in the lower cover.
2. Using the diagonal cutting pliers, cut the plastic ties that secure the battery to the
frame.
Note: Be sure to cut only the white plastic ties that are wrapped around the
battery and secure it to the lower cover. Do not cut the blue and white
power cables that are connected to the top of the battery.
3. Remove the battery, being careful not to snag any components when pulling the
cable out from underneath the main circuit board. If the battery well contains
tape, remove the tape.
4. Remove the liner from the tape on the bottom of the new battery, and place the
new battery in the battery well with the tape side down, ensuring that the blue and
white cables are facing up, then route the new plastic ties (packaged with the
replacement battery) underneath the battery well.
Plastic Tie
Plastic Tie
Blue and White
Battery Cable
New Plastic Tie
New Battery
New Plastic Tie
