ITC AVOXimeter 1000E Operator’s Manual
49
5.
If needed, enter the pulmonary flow and systemic flow, using the number keys.
After each value is entered, check that the value is correct and press
to
move the cursor to the next line.
Note:
If pulmonary flow and systemic flow were already calculated, the values
will be displayed.
If an incorrect value is displayed, delete numerals from the right by
pressing
once for each numeral to be deleted.
6.
After all values have been entered, press
to confirm. The calculated flow ratio
is displayed:
7.
Press
when done. The menu of flow calculations is again displayed.
8.
Press
to return to the previous menu, if desired.
Calculating Cardiac Index:
1.
Display page 2 of the “Hemodynamics” menu (a submenu of
2.
Press
followed by
. A menu of flow calculations is displayed:
3.
Press
followed by
. The screen for entering cardiac output and body
surface area is displayed:
4.
If needed, enter the cardiac output and body surface area, using the number keys.
After each value is entered, check that the value is correct and press
to
move the cursor to the next line.
Note:
If cardiac output and body surface area were already calculated, the
values will be displayed.
If an incorrect value is displayed, delete numerals from the right by
pressing
once for each numeral to be deleted.
