WINDSHIELD MOUNTING
Mount the DashDAQ on the windshield in a spot that does not obstruct the view of the road or in any way that interferes with the safe
operation of the vehicle.
Mounting Suggestions:
•
Mount the DashDAQ as low to the dashboard as possible.
•
Mounting to the left or in the middle works well.
CONNECTIONS
Accessory Port
OBD II Port
Audio Output
USB Update
Port
USB Ports
Power Button
MMC SD Memory
Card Slot
Light Sensor
