Drew Technologies DASHDAQ-XL User Manual
Page 22
22
To view log files:
1. Remove the SD memory card from the DashDAQ.
2. Place the memory card into a SD card reader and attach to your PC.
3. Open the contents of the card. Log files are saved in the “logs” directory on the card. Log files may be opened in Microsoft
Excel or any other spreadsheet program that accepts *.csv files. Logworks *.dif can be viewed in the Logworks program
available from Innovate Motorsports for free at
www.innovatemotorsports.com
.
CALCULATORS
DashDAQ offers a variety of calculators that can be used to make custom signals using one or more input signals or using user defined
values. These calculators come pre-installed on your DashDAQ.
INSTALLING A CALCULATOR DRIVER
How to install the Fuel Economy calculator:
1. From the Main Menu tap [Setup] >> [Devices] >> [Manager]
2. In the Device Manager select an unused port, then tap [Add Device].
3. Use the [<<] or [>>] to locate the Calculator driver list. Select the driver you would like to install and tap [Install].
4. The calculator will then be added to the Device Manager list.
Selecting the next unused row
Configure the driver and assign it to a port
