32 Amico Accessories Inc.
System
FIT Station Storage
WARNING Remove all un-fixed equipment from the top of the keyboard tray before folding
the FIT station
WARNING Storing the FIT station with the height locking lever facing the wall may result in
the lever hitting the wall. The lever may be removed before storage.
NOTE: FIT Stations can easily be folded to free up floor space when not in use.
NOTE: The following folding procedure assumes the FIT Station is in the default arm position. (Figure 1) and applies to
both arms with extension and without
1. Decide which side of the channel will be used to store the unit. Release the height locking lever on FIT stations
and raise it to the highest vertical position.
NOTE: If the monitor interferes with the folding of the keyboard tray, raise the monitor to the highest position.
2. Push the keyboard tray up and turn the keyboard tray away from the side of the channel that will be used to
store the unit. (Figure 2)
3. Ensure monitor and the swivel post face the same direction as the folded keyboard tray. (Figure 2)
(Figure 2) (Figure 1)
IT Station Default Position
Swivel Post
Keyboard Tray
FIT station example shown above
AHM Arm
Turn monitor
head in the
direction of the
keyboard tray
Keyboard Tray folded and turned to the Right
SECTION 4: Adjustments
