18 YP1125A & YP1625A Table of Contents Index Great Plains Manufacturing, Inc.
401-625M Table of Contents Index 2013-08-13
Store Main Parking Stand
Refer to Figure 10
12. Remove the lower pin
holding the parking
stand . Swing the parking stand back and up until it
is above the rear hole . Place the holding pin in the
rear hole and allow the parking stand to rest on it.
This will be the transport position for the parking
stand.
13. Adjust the top link of a 3-point long enough so the
ball swivel does not bottom out when fully raised.
14. Secure hoses using hose post loops (not shown) so
that hoses have ample slack for lifts and turns, but
cannot get caught in tongue lock or ball swivel.
Failure to do so could cause hose to be crushed
requiring hose replacement.
15. If equipped with hydraulic hitch option, connect
safety chain to a suitable anchor point on the tractor.
Lock Up Fertilizer Drive
YP1225A serial number B1059E+
YP1625A serial number B1106F+
Loss of Control and Sharp Object/Crushing Hazards:
Do not lift or lower wheel by spoke or rim; use handle only.
Keep legs and feet out from under wheel. 90 pounds (41 kg)
force is required to lift wheel. If you lose your grip before
pinning, or after unpinning, the arm snaps down rapidly. The
traction teeth and the force of the wheel impact can inflict
serious injury.
The liquid fertilizer option uses a piston pump driven by a
ground contact wheel. When not using the fertilizer drive,
preserve the pump by locking up the ground wheel. On
older models remove the chain.
Note: Do not operate planter pump when not applying
material.
Refer to Figure 11
For YP1225A and YP1625A planters:
16. Remove clevis pin from storage hole .
17. Release the lock arm , lift handle to lift ground
wheel up to position it in-between lock arm.
18. Secure with pin clevis and cotter pin.
Figure 10
Storing Parking Stand
22813
5
6
7
5
7
6
Figure 11
Locked Up Fertilizer Drive
32364
5
7
6
4
4
5 7
6
