IN100 Mortise Lock
1 52-4481 Reader Assembly* 1
2 52-1332 Gasket (Optional) 1
3 52-2847 Conduit Pack (Optional) 1
4 52-1370 Fire Shield* 1
5 52-1327 Mounting Plate 1
6 52-4488 Screw Pack 1
7 52-4486 Controller Module 1
8 01-0898 AA battery 6
9 52-4483 Inside Cover Assembly 1
10 52-4321 Door Position Switch Pack 1
11 A8120 Field Prep Template (not shown) 1
12 4697 Door Manufacturers Template (not shown) 1
13 A8122 Instructions (not shown) 1
14 C2-7976-hand-finish Lock body with dead bolt with Cylinder 1
C2-7977-hand-finish Lock body with dead bolt without Cylinder
C2-7978-hand-finish Lock body without dead bolt with Cylinder
C2-7979-hand-finish Lock body without dead bolt without Cylinder
15 79-0035 Without dead bolt 1
79-0036 With dead bolt (shown) 1
16 77-4236 Mortise Screw Pack - Specify Finish (Includes: Wood and Metal
Lock body Screws, Faceplate Screws, and Strike Screws)
1
17 Consult Factory #41 Mortise Cylinder 1
18 13-2131 97 Ring 1
19 77-4081 130W Turn Lever 1
20 Consult Factory Reference Incepta Catalog 2
21 78-3696 O-rose 2
22 79-2162 Trim Pack 1
ITEM PART NO. DESCRIPTION QTY.
Parts Breakdown 13.56 MHz iCLASS (Continued)
* Patent Pending
