ULTRA-CUT 400 XT

3-8

INSTALLATION

Manual 0-5275

to bare metal. Use lock washers to keep the connections tight. Using electrical joint compound to prevent corrosion is also

recommended.

6. The plasma power supply chassis is connected to the power distribution system ground as required by electrical codes. If

the plasma supply is close to the cutting table (see NOTE) a second ground rod is not usually needed, in fact it could be

detrimental as it can set up ground loop currents that cause interference.

When the plasma power supply is far away from the ground rod and interference is experienced, it may help to install a second

earth ground rod next to the plasma power supply. The plasma power supply chassis would then be connected to this ground

rod.

NOTE

It is recommended that the Plasma Power Supply be within 20 - 30 ft (6.1 – 9.1 m) of the cutting table, if possible.

7. The plasma control cable should be shielded with the shield connected only at the cutting machine end. Con-

necting the shield at both ends will allow ground loop currents which may cause more interference than with no
shield at all.

Creating An Earth Ground

1. To create a solid, low resistance, earth ground, drive a 1/2 in (12 mm) or greater diameter copper clad ground rod at least 6 - 8

ft (1.8 - 2.4 m) into the earth so that the rod contacts moist soil over most of its length. Depending on location, a greater depth

may be required to obtain a low resistance ground (see NOTE). Ground rods, typically 10 ft (3.0 m) long, may be welded end

to end for greater lengths. Locate the rod as close as possible to the work table. Install a ground wire, 1/0 AWG (European

50 mm2) or greater, between the ground rod and the star ground point on the cutting table.

NOTE

Ideally, a properly installed ground rod will have a resistance of three ohms or less.

To test for a proper earth ground, refer to the following diagram. Ideally, the reading on the multimeter should be as shown.

CAUTION

No other connections should be made at the ground rod being tested.
