ULTRA-CUT 400 XT
2-2 SPECIFICATIONS Manual 0-5275
NOTE
* Suggested wire size based on United States NFPA 70 National Electrical Code 2011 edition pub�
lished by the National Fire Prevention Association. Listings are from table 400.5(A)(2) for flexible cord
of certain types rated for 75 deg C in ambient temperatures up to �0 deg C. Using wires of lower tem� deg C in ambient temperatures up to �0 deg C. Using wires of lower tem� C in ambient temperatures up to �0 deg C. Using wires of lower tem�
perature rating or different insulation type may require larger wire size. De rate for higher ambient.
These are suggestions only. Always refer to your local and national codes that apply to your region for final deter�
mination of correct wire type and size.
2.07 Power Supply Dimensions
Art # A-11982
35.97 inch
914 mm
27.6 inch
701 mm
47.77 inch
1213 mm
400A 580 lb / 263 kg
