TECHNICAL SPECIFICATIONS
Overall Dimensions:
6.62”H x 4.82”W x 2.65”D
Flash Patterns:
7 fl ash patterns
Input Voltage Range:
10 - 30 Vdc
Input Current @12Vdc:
6 Amps (ETN660-P)
9 Amps (ETG690-P)
11 Amps (ETG6110)
Output Power:
60 Watts (ETN660-P)
90 Watts (ETG690-P)
110 Watts (ETG6110)
# of Outputs:
6
Operating Temperature:
-40º to +65º C
Contents:
1 ea. Strobe Power Supply
1 ea. 3 pin power input
harness (Red, Black, Violet)
1 ea. 3 pin control input
harness (Blue, Green, Yellow)
1 ea. Installation Instructions
ET(x)6(xxx) 9.09
STROBE POWER SUPPLY
ETN660-P / ETG690-P / ETG6110
POWER INPUT / CONTROL WIRES
WIRE COLOR:
CONNECT TO:
BLUE (+10-30Vdc)
Activates Heads 1-2
GREEN (+10-30Vdc)
Activates Heads 3-4
YELLOW (+10-30Vdc)
Activates Heads 5-6
VIOLET (+10-30Vdc)
Activates Low Power Mode
VIOLET (MOMENTARY
GROUND)
Changes Pattern
FLASH ENERGY
ETN660-P
ETG690-P
ETG6110
PATTERN:
JOULES
(PRIMARY)
JOULES
(SECONDARY)
JOULES
(PRIMARY)
JOULES
(SECONDARY)
JOULES
(PRIMARY)
JOULES
(SECONDARY)
Quad:
10.3
5.1
14
7.6
17
8.4
Double:
10.3
5.1
14
7.6
17
8.4
Quint:
5.1
5.1
7.6
7.6
8.4
8.5?
Warp:
5.1
-
7.6
-
8.4
-
Inter-Cycle
5.1
5.1
7.6
7.6
8.4
8.4
Triple:
10.3
5.1
14
7.6
17
8.4
Single:
10.3
-
14
-
17
-
FLASH PATTERNS
PATTERN
TIME-
PRIMARY
TIME-
SECONDARY
FLASHES /
MINUTE
Quad
170mS
85mS
70
Double
170mS
85mS
115
Quint
85mS
85mS
70
Warp
85mS
-
350
Inter-Cycle
85mS
85mS
-
Triple
85mS
85mS
90
Single
-
-
175
