1.800.338.7337 / www.soundoffsignal.com

EGHST1(xx)-12 7.14

1 SINGLE LIGHT

Follow the ID selection steps and set the GHOST to the following ID:

- Alternating (default): ID#1 or ID#3. (inludes cycle patterns

and steady burn patterns)

- Simultaneous: ID#2 or ID#4. (both lights will flash together

regardless of pattern)

2 SINGLE LIGHTS

Follow the ID selection steps and set the GHOST to the following ID:

***IMPORTANT: Make sure both lights flash the same pattern!***

- Both assemblies simultaneous with individual lights alternating.

- Example: Driver/Passenger sim; Dr.(left alt right)

Pass.(left alt right)

- Set both GHOST Assemblies to ID#1

- Both assys. alternating with individual lights alternating.

- EX: Dr./Pass. alt; Dr.(left. alt. right.) Pass.(right alt. left)

- Set one GHOST to ID#1 and the other to ID#3

- Both assys. alternating with individual lights simultaneous

- EX: Dr./Pass. alt; Dr.(left sim left) Pass.(right sim right)

- Set one GHOST to ID#2 and the other to ID#4

- Both assys. simultaneous with individual lights simultaneous.

- EX: Dr./Dr. sim; Dr.(left sim left) Pass.(right sim right)

- Set both Ghost housings to ID#2

X-PATTERN - To obtain X-Patterns, follow the ID SELECTION steps and set

one of the four GHOST lights to ID#1, one to ID#2, one to ID#3, and

one to ID#4. Then proceed to the PATTERN SELECTION steps.

NOTE: Be sure to mount each GHOST in the correct placement

based on ID#.

PATTERN SELECTION

1. Disconnect WHITE wire from any connections if applicable.

2. Turn GHOST ON.

3. Momentarily touching and removing the WHITE wire(s) to ground

will advance the GHOST to the next flash pattern. Touching and removing

the White wire for more than a few seconds will allow you to change the

GHOST to the previous pattern. See flash pattern table. Continuing to

touch and remove the WHITE wire(s) to ground will allow you to scroll

through the pattern list. After pattern #33 is reached the list will start over

again at pattern #1.

NOTE: The GHOST is equipped with flash pattern memory. Once you have

selected a pattern the GHOST will always activate to that pattern every time

the unit is turned on. Tape up and secure WHITE wire so that it will not ac-

cidentally change your selected pattern.

Ghost Sync Configuration Instructions

IMPORTANT! A MAXIMUM OF 4 SINGLE LIGHTS

CAN BE SYNCED TOGETHER

1. Set ID#

a. Identify which pattern and sequence you want and look up

ID# settings at left.

b. Connections

i. RED:

+10-16Vdc

ii. WHT: +10-16Vdc (Note: you will need to disconnect

after power is applied)

iii.

BLK:

Ground

c. Apply power to unit

d. Without disconnecting power from unit,

disconnect WHT wire

e. Momentarily connect WHT to Ground to change ID #

i. Identify ID# by number of sequential flashes

ii. Possible ID#s: 1 – 4

f. Disconnect power from unit to get out of ID mode.

2. Set Pattern

a. Reapply power to units.

b. Once all Light Head ID#s are configured, make sure all

lights are flashing the same pattern.

c. Connect corresponding colored wires of all units together:

RED to RED, etc.

d. Change Pattern

i. Momentarily connect WHT wires to Ground

ii. Observe pattern change on all lights connected

e. Insulate all wires by taping with electrical tape

3. Connect Master Switch for Application

a. IMPORTANT! Ensure WHT Pattern/Sync Wires are tied

together.

PATTERN RESET

1. Remove power

2. Place WHITE (sync) wire to ground

3. With sync wire grounded, re-power RED wire

4. Maintain for one second (light will dim)

5. Remove power and ground (pattern 1 set)

SLAVE MODE

The GHOST is capable of being activated through the use of a user

supplied flasher by putting it in slave mode.

Flash Patterns

Pattern Name

1 Light

Alternating 2

Lights

Silmultaneous

2 Lights

X-Pattern

4 Lights

F.P.M.

(Flashes / Minute)

1. Quint

x

x

x

70

2. Warp

x

x

x

350

3. Inter-Cycle Flash

x

x

4. Double Flash

x

x

x

70

5. Quad Flash

x

x

x

80

6. PowerPulse

x

x

x

180

7. RoadRunner

x

x

x

113

8. Q-Switch

x

x

9. RoadRunner Steady Burn

x

x

113

10. Quad Steady Burn

x

x

80

11. E-Ideal Single Flash

x

x

x

200

12. E-Ideal Double Flash

x

x

x

146

13. Quad2 Flash

x

x

x

67

14. Double2 Flash

x

x

x

95

15. X-Warp

x

16. X-Double

x

17. PowerRunner

x

x

x

18. LCR Quint

x

x

x

19. Warp

3

x

x

x

20. Ultra Warp

x

x

x

545

21. Thunder & Lightning

x

x

22. Lite Speed

x

x

x

85

23. SuperSonic

x

x

170

24. LCR Lite Speed

x

x

x

25. SuperSonic Ultra

x

x

x

26. Tempo Shift

x

x

x

27. Tempo Shift Warp

x

x

x

28. SBE2

x

x

x

67

29. C

2

x

x

x

200

30. U

2

x

x

x

176

31. Ultra Glow

x

x

x

32. Cyclone

x

x

x

33. Chameleon

x

x

x

X-Pattern Sequence

ID#1> ID#4> ID#2> ID#3

X-Pattern Light Head Placement

ID#4 ID#2

ID#3 ID#1

1. Permanently connect the GHOST WHITE and BLACK wire to a

good, convenient ground.

2. Connect the GHOST RED wire, through a 5Amp fuse, to the output

of a +10-16Vdc switching flasher.

GHOST® DUAL MULTI-MOUNT LIGHT

EGHST1(x)-12 - Black
EGHST1(x)W-12 - White
