FUSION LED LIGHT
#EFL1(x)Ø(x)
#EFL2(x)0(x)
EFL1B0(x)_EFL1W0(x) 8.14
Pg. 2
1.800.338.7337 / www.soundoffsignal.com
IMPORTANT INFORMATION:
Warning devices are strictly regulated and governed by Federal, State and Municipal ordinances. These devices shall be used ONLY on approved vehicles. It is the sole responsibility of the user of these devices to ensure compliance.
To review our Limited Warranty Statement & Return Policy for this or any SoundOff Signal product, visit our website at
www.soundoffsignal.com/sales-support.
If you have questions regarding this product, contact
Technical Services, Monday - Friday, 8 a.m. to 5 p.m. at 1.800338.7337 (press #4 to skip the automated message).
Questions or comments that do not require immediate attention may be emailed to
SUPERIOR CUSTOMER RELATIONSHIPS. SMARTLY DESIGNED LIGHTING & ELECTRONIC SOLUTIONS.
PATTERN SELECT
1. With light powered, touch White wire to Red Power wire for 1
second.
PATTERN RESET
1. With light powered, touch White wire to Red wire for 3
seconds.
2. Remove White wire from power. Pattern resets to 1.
SYNC MULTIPLE LIGHTS
1. Set up all lights to the same pattern
2. Connect White wires of all lights to sync together.
a. Note, only 6 lights can be synced together.
b. Insulate connections
3. Green Wire Connection
a. For Simultaneous Flashing of a group of lights:
i. Connect all Green wires together of the group of lights
desired to flash in unison.
ii. All Green wires connected together form one light group
b. For alternating flashing of a group of lights:
i. Connect one group of Green wires to Power (+Vdc)
ii. These lights will flash in unison.
iii. Connect one group of Green wires together but leave
floating.
iv. These lights will flash in unison.
v. Together, both light groups will alternate.
vi. For two lights simply connect one Green wire to Power
(+Vdc) and leave the other Green wire floating.
vii. Insulate connections.
Tech Specs
Fusion Lite
Flash Patterns:
6 Flash Patterns
Light Sync:
Yes
Technology:
1 Gen3 LED
Mounting:
Surface Mount
Input Voltage:
10 - 16 Vdc
Current Draw:
less than 0.1 amps
Dimensions:
Width x Height x Depth
3.125” (79.4 mm) W x 1.5” (38.5 mm)
H x .75” (19.5 mm) D
Operating Temp.:
-20° to +65° C
Flash Patterns
Pattern Name
SAE
Pattern
ECE
Pattern
1 Light
F.P.M.
(Flashes / Minute)
1. Warp
x
x
353
2. Power Pulse
x
x
182
3. Road Runner
x
x
113
4. ECE Single
x
x
62
5. ECE Double
x
x
144
6. Quad
x
x
81
