NOTE: GHOST is equipped with Flash Pattern Recall. Once you
have selected a pattern the light will always activate to that pat-
tern every time the unit is turned on. Tape up and secure WHITE
wire so that it will not accidentally change your selected pattern.
LIGHT SYNC CONFIGURATION INSTRUCTIONS
IMPORTANT! A MAXIMUM OF 2 DUAL LIGHTS CAN BE SYNCED.
1. Set ID #:
a. Identify which pattern and sequence you want and look up
ID # settings at left.
b. Connections
i. RED: +10 - 16 Vdc
ii. WHITE: +10 - 16 Vdc
(Note: you will need to disconnect after power is applied)
iii. BLACK:
Ground
c. Apply power to unit
d. Without disconnecting power from unit, disconnect
WHITE
wire
e. Momentarily connect WHITE to Ground to change ID #
i. Identify ID # by number of sequential flashes
ii. Possible ID #s: 1 – 4
f. Disconnect power from unit to get out of ID mode
2. Set Flash Pattern:
a. Reapply power to units
b. Once all Light Head ID #s are configured, make sure all
lights are flashing the same pattern.
c. Connect corresponding colored wires of all units together:
RED to RED, etc.
d. To Change Flash Pattern:
i. Momentarily connect WHITE wires to Ground
ii. Observe pattern change on all lights connected
e. Insulate all wires by taping with electrical tape
3. Connect Master Switch:
a. IMPORTANT! Ensure WHITE Pattern/Sync Wires are tied
together
SLAVE MODE
GHOST Surface Mount is capable of being activated through the
use of a user supplied flasher by putting it in Slave Mode.
1. Permanently connect the WHITE and BLACK wires to a good,
convenient ground.
2. Connect the RED wire, through a 5 Amp fuse, to the output of a
+10 - 16 Vdc switching flasher.
PATTERN RESET
1. Remove power
2. Place WHITE (sync) wire to ground
3. With sync wire grounded, re-power RED wire
4. Maintain for one second (light will dim)
5. Remove power and ground (pattern 1 set)
1 (one) LIGHT
Follow the Light Sync Configuration Instructions and set the GHOST
light to the following ID:
- Alternating (default): ID #1 or ID #3 (inludes cycle patterns
and steady burn patterns)
- Simultaneous: ID #2 or ID #4 (both lights will flash together
regardless of pattern)
2 (two) LIGHTS
Follow the Light Sync Configuration Instructions and set the GHOST
lights to the following ID:
IMPORTANT: Make sure both lights flash the same pattern!
- Both assemblies simultaneous with individual lights alternating.
- Example: Driver/Passenger sim; Dr.(left alt right)
Pass.(left alt right)
- Set both GHOST Assemblies to ID #1
- Both assys. alternating with individual lights alternating.
- EX: Dr./Pass. alt; Dr.(left. alt. right.) Pass.(right alt. left)
- Set one GHOST to ID #1 and the other to ID #3
- Both assys. alternating with individual lights simultaneous
- EX: Dr./Pass. alt; Dr.(left sim left) Pass.(right sim right)
- Set one GHOST to ID #2 and the other to ID #4
- Both assys. simultaneous with individual lights simultaneous.
- EX: Dr./Dr. sim; Dr.(left sim left) Pass.(right sim right)
- Set both GHOST housings to ID #2
X-PATTERN - To obtain X-Patterns, follow the ID SELECTION steps
and set one of the four GHOST lights to ID #1, one to ID #2, one to
ID #3, and one to ID #4. Then proceed to the PATTERN SELECTION
steps.
NOTE: Be sure to mount each GHOST in the correct placement based
on ID#.
PATTERN SELECTION
1. Disconnect WHITE wire from any connections if applicable.
2. Turn GHOST ON.
3. Momentarily touching and removing the WHITE wire(s) to ground
will advance the GHOST to the next flash pattern. Touching and
removing the White wire for more than a few seconds will allow
you to change the GHOST to the previous pattern. See flash pattern
table. Continuing to touch and remove the WHITE wire(s) to ground
will allow you to scroll through the pattern list. After pattern #33 is
reached the list will start over again at pattern #1.
X-PATTERN SEQUENCE
X-PATTERN LIGHT HEAD PLACEMENT
ID#1>ID#4>ID#2>ID#3
ID#4
ID#2
ID#3
ID#1
Flash Patterns
Flash Pattern Name
1 Light
2 Lights
Alternating
2 Lights
Silmultaneous
4 Lights
X-Pattern
Flashes per
Minute (FPM)
1. Quint
x
x
x
70
2. Warp
x
x
x
350
3. Inter-Cycle Flash
x
x
4. Double Flash
x
x
x
70
5. Quad Flash
x
x
x
80
6. PowerPulse
x
x
x
180
7. RoadRunner
x
x
x
113
8. Q-Switch
x
x
9. RoadRunner Steady
Burn
x
x
113
10. Quad Steady Burn
x
x
80
11. E-Ideal Single Flash
x
x
x
200
12. E-Ideal Double Flash
x
x
x
146
13. Quad2 Flash
x
x
x
67
14. Double2 Flash
x
x
x
95
15. X-Warp
x
16. X-Double
x
17. PowerRunner
x
x
x
18. LCR Quint
x
x
x
19. Warp
3
x
x
x
20. Ultra Warp
x
x
x
545
21. Thunder & Lightning
x
x
22. Lite Speed
x
x
x
85
23. SuperSonic
x
x
170
24. LCR Lite Speed
x
x
x
25. SuperSonic Ultra
x
x
x
26. Tempo Shift
x
x
x
27. Tempo Shift Warp
x
x
x
28. SBE2
x
x
x
67
29. C
2
x
x
x
200
30. U
2
x
x
x
176
31. Ultra Glow
x
x
x
32. Cyclone
x
x
x
33. Chameleon
x
x
x
